Artist’s Impression of CarbSAR Satellite Orbiting the Earth Credit: Oxford Space Systems
Britain’s newest satellite, **CarbSAR**, is set to launch on Sunday, equipped with cutting-edge knitwear technology. This innovative satellite will deploy a mesh radar antenna crafted using machinery typically found in textile manufacturing.
“We utilize a standard industrial knitting machine for jumpers, enhanced with features tailored to create specialized threads,” says Amur Raina, Director of Production at Oxford Space Systems (OSS) in the UK.
OSS collaborates with Surrey Satellite Technology Limited (SSTL) to install the antenna on a compact, cost-effective spacecraft capable of capturing high-resolution images of the Earth’s surface.
If successful, this unique design could be integrated into the UK Ministry of Defence’s (MoD) surveillance satellite network later this year.
The “wool” utilized in OSS’s weaving process is ultra-fine tungsten wire, coated with gold. The machines produce several meters of fabric simultaneously, which are then cut into segments and sewn into 3 millimeter-wide discs. These discs are tightly stretched over 48 carbon fiber ribs to form a smooth parabolic dish optimized for radar imaging.
The key innovation lies in the structural design, where each rib wraps radially around a central hub, resembling a 48-coil tape measure. This unique design enables the entire assembly to collapse down to just 75 cm in diameter, drastically reducing the volume of the 140-kilogram CarbSAR satellite during launch.
Upon reaching orbit, the stored strain energy in the bent carbon fibers will allow the ribs to return to their original shape, thereby pulling the mesh into a precise parabolic configuration.
“For optimal imaging, we must deploy it accurately to achieve the perfect parabolic shape,” adds Sean Sutcliffe, CEO of OSS. “Our design’s precision is its standout feature.” Testing has shown the mesh sheet remains within 1 millimeter of its ideal shape, ensuring exceptional performance.
The demand for Earth observation via small radar satellites is on the rise, thanks to their ability to image the ground in all weather conditions and even at night—a capability increasingly appreciated by emerging space companies.
This data is particularly sought after by military forces globally and played a crucial role as an intelligence resource during the recent Russian-Ukrainian conflict.
Despite once leading Europe in space radar developments in the 1990s, the UK has fallen significantly behind in the international arena.
With CarbSAR and the upcoming MoD constellation named Oberon, part of the broader ISTARI program, UK aerospace engineers have a chance to re-establish their presence in the industry.
“We’re seeing heightened interest from foreign governments in radar solutions,” states Andrew Cawthorn, Managing Director of SSTL. “Our primary focus is demonstrating that we can successfully deploy this antenna and capture images.”
CarbSAR is engineered to detect objects as small as 50 cm, sufficient for identifying tanks and aircraft.
After deployment, approximately two days post-liftoff, the Royal Space Force, supervised by the Royal Air Force, will closely monitor the antenna’s performance.
“CarbSAR symbolizes the innovative spirit and collaboration of one of the UK’s leading space companies,” said Major General Paul Tedman, Commander of the UK Space Force. “We eagerly anticipate seeing CarbSAR operational and exploring how its advanced technologies can enhance Oberon and our comprehensive ISTARI satellite initiative.”
